damascene-winit-wgpu

Optional native desktop host for Damascene apps using winit and wgpu.

Use this crate when you want the host to own the window, surface, swapchain, input mapping, IME forwarding, animation redraws, and MSAA target management:

use damascene_core::prelude::*;

fn main() -> Result<(), Box<dyn std::error::Error>> {
    let viewport = Rect::new(0.0, 0.0, 720.0, 480.0);
    damascene_winit_wgpu::run("My Damascene App", viewport, MyApp::default())
}

For apps with external live state, put per-frame refresh in App::before_build, then use run_with_config and pick the redraw driver that matches your data (see below): a host cadence via HostConfig::with_redraw_interval, or push-driven wakes via HostConfig::with_external_wakeup. For custom render-loop integration, bypass this crate and call damascene-wgpu::Runner directly.

Live data: meter-class vs event-class

External live state divides cleanly into two patterns, and apps that get the choice wrong burn either CPU or responsiveness.

Meter-class — high-frequency, value-changes-every-tick: audio peak meters, FPS counters, network throughput graphs. The right shape is fixed-cadence polling at the display refresh rate (33 ms ≈ 30 fps is plenty for a peak meter; faster wastes work). Use HostConfig::with_redraw_interval(Duration) and snapshot the latest value in App::before_build. damascene-volume's PipeWire peak meter is the worked example.

Event-class — sparse, value-changes-on-discrete-event: a chat message arrived, a download finished, a USB device was plugged in, a config file changed on disk. The right shape is push-driven — the backend thread wakes the UI loop as the event happens, with no polling. Polling event-class data either burns CPU at a useless cadence or shows the change up to one polling interval late.

Use HostConfig::with_external_wakeup for the push path. The hook runs once, just before the event loop starts, and hands you a Wakeup — a Send + Clone handle any thread can poke to schedule one frame. Snapshot the changed state in App::before_build as usual; between wakes the idle app renders at 0 fps:

let (tx, rx) = std::sync::mpsc::channel();
let config = HostConfig::default().with_external_wakeup(move |wakeup| {
    let _ = tx.send(wakeup);
});
// The thread that drains your backend's event subscription decides
// which events warrant a frame, then pokes the host:
std::thread::spawn(move || {
    let wakeup = rx.recv().unwrap();
    // for each interesting backend event:
    wakeup.wake();
});

Wakes coalesce — a burst of N pokes before the next frame produces one redraw — and a poke is safe at any time: from any thread, before the first frame, or after the loop exits (then it's a no-op).

If your app needs both — fixed-cadence meters and push-driven events — the two drivers don't conflict; and if the meter is only sometimes on screen, prefer driving it with redraw_within from the meter widget itself so the cadence stops when the widget leaves the tree. The trade-off itself is the load-bearing piece — recognize which axis your data falls on before reaching for the host config.
